IO terminal MULTITOOL PSA BSI software

MULTITOOL PSA BSI (activation/simcard)

This software can offer functions that normally would normally require the ECU to be opened and a BDM/Boot programmer connected, however, it can accomplish these procedures without opening the ECU and in some cases all from OBD.

You can read/write EEPROM and internal/external flash memories (where available)

All operations are done over K-line or CAN bus without the need to open BSI!

Bench read/write only!

Supported PSA BSI ECU’s:

Siemens D76F0018+95160 KLINE (BSI-E0X-00/BSI-F0X-00) – EEPROM 95160 R/W , show PIN

Siemens 1L00M+95128/95256 CAN (BSI-S0X-00) – EEPROM 95128/95256 R/W, show PIN, 9S12DP512 FLASH R/W

Continental SC667050+95256 CAN (BSI-Q0X-00) – EEPROM 95256 R/W, show PIN, SC667050 FLASH R/W

Valeo 4L00M+95128/25128 CAN (BSI2004-P0X-00) – EEPROM 95128/25128 R/W, show PIN, 9S12DP512 FLASH R/W

Valeo 2M48H+24C128 CAN (BSIEV-X0X-00) – EEPROM 24C128 R/W, show PIN, 9S12XEP768 FLASH R/W

Valeo SC667152+95256 CAN (BSI-N0X-00) – EEPROM 95256 R/W, show PIN, SC667152 FLASH R/W

Johnson Controls easyCAN4+29LV400+95128 CAN (BSI2004-H0X) – EEPROM 95128 R/W, show PIN, 29LV400BB FLASH R/W

Johnson Controls easyCAN4F1M-32+95128 CAN (BSI04EV-K0X) – EEPROM 95128 R/W, show PIN, easyCAN4F1M-32 FLASH R/W

Johnson Controls SPC560B60+95128 CAN (BSI04EV2-KEX) – EEPROM 95128 R/W, show PIN,SPC560B60 FLASH R/W

NOTE: For IO terminal MULTITOOL PSA BSI  software you can activate this software in basic software card else you need new sim-card.
