7G (VGS4-NAG2) TCU Virgin and Personalization by Diagnostic CAN

Requirements: AMS+I18 +MN032

If previously read FBS4 personalization data is not available, you can use MN034 license.

No explicit setting to virgin state!

It eliminates the need to open/cut the module and makes it so much easier to re-use second-hand TCUs!

Faster, easier and safer solution!

Functionalities:

Read FBS4 data from VGS4-0 NAG2 modules via OBD or on bench*

Write FBS4 personalization data to the TCU via OBD and internal CAN-Bus** or on bench*

Using this software license, you can personalise used VGS4-0 NAG2 transmission control units by reading the FBS4 data from the original module and writing the previous one’s data on the replacement module, all by OBD and internal CAN-Bus** connection or on bench*.

Supported vehicles:

All Mercedes-Benz passenger vehicles from the FBS4/DAS4 immobilizer generation, equipped with 7G-Tronic (VGS4-0 NAG2) Transmission Control Units

MN032 license, and AVDI with active annual subscription are required.

*Bench connection can be established via CB088

**Internal CAN-Bus connection can be established via CB012

N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
