IO terminal MARELLI+MARELLI2 software

IO terminal MARELLI+MARELLI2  software simcard-software read/write full flash memories for Magneti Marelli ECUS.  All operations done via k_line or CAN and no need to open ECU.

The device works only through the IO Terminal software and the corresponding SIM card or by activation and has the following software:

IO terminal MARELLI+MARELLI2 (activation/simcard)

Supported ECU:

FIAT – 8FMW CAN – MPC5565 R/W – 95128 R/W

FIAT – 8GMF HW02 CAN – MPC5553 R/W – 95640 R/W

FIAT – 8GMF HW03 CAN – MPC5565 R/W – 95640 R/W

FIAT – 8GMK CAN – SPC564A80B4 R/W – 95640 R/W

FIAT – 8GSF CAN – MPC5565 R/W – 95640 R/W

FIAT – 8GSW CAN – MPC5565 R/W – 95640 R/W

FIAT – IAW 10GF CAN/KLINE – MPC5642 R/W – 95640 R/W – included in MULTITOOL software

FIAT – IAW 4AF HW204 KLINE – ST10F168 R/W – 95160 R/W

FIAT – IAW 4AF HW407 KLINE – ST10F269 R/W – 95160 R/W

FIAT – IAW 59F <HW100 KLINE – 29F200BB R/W – 95080 R/W

FIAT – IAW 59F HW303/HW306 KLINE – ST10F168 R/W – 95160 R/W

FIAT – IAW 59F HW603/HW607 KLINE – ST10F269 R/W – 95160 R/W

FIAT – IAW 5AF HW303/HW306 KLINE – ST10F168 R/W – 95160 R/W

FIAT – IAW 5AF HW603/HW607 KLINE – ST10F269 R/W – 95160 R/W

FIAT – IAW 5NF.T1/5NF.T9 KLINE – MC68F375 R – 95160 R/W

FIAT – IAW 5SF.XX KLINE – ST10F280 R/W

FIAT – IAW 5SF3 CAN/KLINE – ST10F280 R/W

FIAT – IAW 5SF4 KLINE – ST10F296 R/W

FIAT – IAW 5SF8 CAN/KLINE – ST10F296 R/W

FIAT – IAW 5SF9 CAN/KLINE – ST10F296 R/W

FIAT – IAW 7GF CAN/KLINE – MPC5534 R/W – 95640 R/W – included in MULTITOOL software

FIAT – IAW 9GF CAN – MPC5642 R/W – 95640 R/W – included in MULTITO

FIAT – IAW 9GF CAN – SPC564A70L7 R/W – 95640 R/W

FIAT – IAW 9GV CAN/KLINE – MPC5634 R/W – 95320 R/W – included in MULTITOOL software

FIAT – MJD 6F3 CAN/KLINE – MPC563 R/W – M58BW016DB R/W – 95320 R/W

FIAT – MJD 6F3 CAN/KLINE – MPC563 R/W – S29CL016J R/W – 95320 R/W

FIAT – MJD 6JF KLINE – MPC555 R/W – 95320 R/W

FIAT – MJD 8DF KLINE – MPC5553 R/W – 95640 R/W

FIAT – MJD 8F2 CAN/KLINE – MPC5565 R/W – 95640 R/W

FIAT – MJD 8F3 CAN/KLINE – MPC5565 R/W – 95640 R/W

FIAT – MJD 9DF CAN – SPC5644 R/W – 95128 R/W

OPEL – MJD 6JO KLINE – MPC555 R/W – 95320 R/W

OPEL – MJD 6O2 CAN/KLINE – MPC563 R/W – M58BW016DB R/W – 95320 R/W

OPEL – MJD 6O2 CAN/KLINE – MPC563 R/W – S29CL016J R/W – 95320 R/W

OPEL – MJD 6O3 CAN – MPC563 R/W – M58BW016DB R/W – 95320 R/W

SUZUKI – 8DS CAN – MPC5565 R/W – 95640 R/W

SUZUKI – MJD 6O2 KLINE – MPC563 R/W – M58BW016DB R/W – 95320 R/W

NOTE: For IO terminal MARELLI+MARELLI2 software you can activate this software in basic software card else you need new sim-card.
